KVANT Atom Series - Multiple System Interlock

11 | 38
Atom series - v160120
Kvant Lasers s.r.o.
EN
Connection
Diagram
2.6
Please check that all the signal and power leads are correctly installed and that the safety keys are inserted
in all necessary positions.
USA ONLY: Remote Interlock Bypass must be inserted in the E-STOP Remote as well in order to disable
the interlock.
!
Both E-STOP Remote safety key and laser system safety key must be inserted and switched to ON position
in order to disable the interlock.
