KVANT Atom Series Model Specific Operation Manual

36 | 38
Atom series - v160120
Kvant Lasers s.r.o.
EN
Technical Specification
[Atom 20]
KVANT Atom 20 – full colour, semiconductor diode laser system
7.4
Total Optical Power (installed): 21.1W
Total Optical Power (guaranteed): 20W*
Maximum Output Power: 21W
*Due to Advanced Optical Correction technology used in our laser systems the optical power output of each laser colour
within the system may slightly dier from the specification of respective laser module(s) installed. This does not aect
the guaranteed total power output.
NOHD (Nominal Ocular Hazard Distance for guaranteed power output): 999m
Beam diameter at laser aperture: 5.5 × 5.5mm
Beam divergence: <1mrad (full angle)
Modulation: 0-5V analog, up to 50kHz
Module cooling: TEC
Scanning System:
CT6215, 30kpps@8°, max. scanning angle 60° on both axes
CT6215-HP, 36kpps@8°, max. scanning angle 60° on both axes (optional)
Control signal: Ethernet, DMX/ArtNet, ILDA, SD card (via inbuilt FB4 control interface)
Power requirements: 100-240V/50Hz (±5%)
Consumption: 500VA/100-240V
Operation temperature: 10-40°C
Ingress protection rating: IP54
Dimensions (WxDxH): 425 × 330 × 260mm
Weight: 30.5kg
Laser safety features: Keyed interlock, emission delay, magnetic interlock, scan-fail safety,
V-RAD 506 mechanical shutter | reaction time <20ms, adjustable aperture masking plate. This laser system fully complies
with the latest EN 60825-1, FDA regulations and TUV Laser Safety.
Colour Wavelength Maximum Output
Red 637nm 6000mW
Green 520nm 3600mW
Blue 445+460nm 11500mW
