KVANT Atom 15 – full colour, semiconductor diode laser system
7.3
Total Optical Power (installed): 14.9W
Total Optical Power (guaranteed): 14.9W*
Maximum Output Power: 14.9W
*Due to Advanced Optical Correction technology used in our laser systems the optical power output of each laser colour
within the system may slightly dier from the specification of respective laser module(s) installed. This does not aect
the guaranteed total power output.
NOHD (Nominal Ocular Hazard Distance for guaranteed power output): 999m
Beam diameter at laser aperture: 5 × 5mm
Beam divergence: <1mrad (full angle)
Modulation: 0-5V analog, up to 50kHz
Module cooling: TEC
Scanning System:
CT6215, 30kpps@8°, max. scanning angle 60° on both axes
CT6215-HP, 36kpps@8°, max. scanning angle 60° on both axes (optional)
Control signal: Ethernet, DMX/ArtNet, ILDA, SD card (via inbuilt FB4 control interface)
Power requirements: 100-240V/50Hz (±5%)
Consumption: 500VA/100-240V
Operation temperature: 10-40°C
Ingress protection rating: IP54
Dimensions (WxDxH): 425 × 330 × 260mm
Weight: 30.5kg
Laser safety features: Keyed interlock, emission delay, magnetic interlock, scan-fail safety,
V-RAD 506 mechanical shutter | reaction time <20ms, adjustable aperture masking plate. This laser system fully complies
with the latest EN 60825-1, FDA regulations and TUV Laser Safety.
Colour Wavelength Maximum Output
Red 637nm 4800mW
Green 520nm 3600mW
Blue 445nm 6500mW
