26 | 38
Atom series - v160120
Kvant Lasers s.r.o.
EN
Beam Alignment
6
It is possible that due to transportation, rigging, moving around or vibrations caused by various elements during a set up
or laser performance some of the internal optical parts can move slightly resulting in colour misalignment.
The colour misalignment is when two or more colours (red, green and blue) physically do not overlay each other properly
like on the picture below. This makes it impossible to get nicely mixed colours like yellow, cyan, magenta and white
(including all their shades). If this occurs it is necessary to carry out the beam alignment procedure.
Be cautious when aligning the beams and wear sucient laser safety protection to avoid accidental
exposure to Class 4 laser radiation.
!
