27 | 38
Atom series - v160120
Kvant Lasers s.r.o.
EN
Beam alignment principle
There are three laser modules within this system where each module produces one of the basic RGB colours (red, green
or blue).
The goal of the alignment procedure is to align all three beams (colours) so they overlay each other nicely while they hit
exact centre of the bottom scanning mirror.
An easiest way to do the alignment is to project a full size circle onto a wall (or any another suitable projection surface),
change its colour as necessary and check the alignment of individual colours on both X and Y axes.
When doing the alignment on long distances it is always good to have someone with you who can point you in the right
direction. Alternatively you can use binoculars.
Remember that greater is the distance between the laser system and the projection surface during
the alignment, more precise the alignment will be.
i
