13 | 38
Atom series - v160120
Kvant Lasers s.r.o.
EN
Switching ON sequence
and User Interlock
2.8
Please make sure that all laser display safety requirements are fulfilled in accordance with laws of the
country where this KVANT laser system is being used before switching the system ON.
!
1. Power loss lasting greater than 2 seconds.
2. Mushroom emergency switch depressed.
3. #2 Key Switch on E-STOP Remote turned to OFF position.
4. #1 Key Switch on laser projector turned to OFF position.
5. Any other interruption to line No.1 of the cable leading to the E-STOP Remote.This includes any user
interlocks connected in series in the line No. 1 of this cable. Refer to Connection Drawing below.
The Interlock is latched enabled and the laser projector’s beam output will be terminated
if any of the following events happen:
After the event has been corrected the START button on the E-STOP Remote must be pressed by the operator to disable
the Interlock and after an Emission Delay period the laser projector will be ready for use.
Interlock Enabled, Laser Output Terminated
Restarting Laser After Interlock or Power Failure Event
1. Connect the system as showed on Connection Diagram.
2. Turn both E-STOP Remote and laser system safety keys to ON position.
3. Release the E-STOP button by pulling it upwards.
4. Open the aperture window by loosening the bolt at the bottom of the aperture, adjust the masking plate
to desired position and tighten the bolt to secure it.
5. Press the Main Power switch located at the back panel.
6. Press the START button on the E-STOP Remote.
7. After an Emission Delay Period the laser projector will be ready for use.
