8. HOW TO SET UP AND OPERATE OF PRODUCT

8-1 Setting data initialize

8-1-1 Initialization function

8-1-1-1 Turn off the power and press at the same time MODE + SET key and turn the power on.

8-1-1-2 After a while, release the key if IN-T is displayed in .

8-1-1-3 Do not turn off the power until IN-T disappears from the display window and the current

vacuum value is displayed. ( You can malfunction when off. )

8-1-1-4 When the vacuum value is displayed, turn off the power and turn it on again.

8-1-2 Initial mode setting value

9. COMMUNICATION FUNCTION AND SETTING OF PRODUCT

9-1 Communication function

9-1-1 Communication is selected by the user's order.

9-1-2 The communication methods are RS48 ASCII and RS485 MODBUS.

9-1-3 Connected units : RS485 ASCII ----> Max 16 units / RS485 MODBUS ----> Max 32 units

9-1-4 Both ASCII, MODBUS require communication address to be set up.

9-1-5 Set the Baudrate as shown in the table below.

DISPLAY VALUE BAUDRATE ( bps )

4-8

4800

9-6

9600

19-2

19200

38-4

38400 ( Default )
