15. TROUBLESHOOTING
15-1 When power is ON but nothing is displayed in the display window:
15-1-1 Check if the 24Vdc is supplied properly from the power supply.
15-1-2 If the power supply is normal and nothing is displayed in the Display window,
please request an A/S from us.
15-2 When atmospheric pressure is continuously displayed even if the pump is down :
15-2-1 You may have randomly manipulated the front key of the controller.
☞ Refer to ( 8-1 ) Setting data initialize
15-2-2 Check if there is any leak between the pumping line and the sensor fitting part.
15-2-3 If sensitivity of the sensor is deteriorated by oxidation or contamination of the filament of the sensor
by corrosive gases, moisture and other impurities, replace the sensor. ( Sensors are consumables. )
15-3 When the vacuum does not stabilize, continuing fluctuating up and down :
15-3-1 There are cases where input power exceeds tolerance range. ( Check AC input power. )
15-3-2 When the types of gases used in the chamber attached to the sensor are H
2
, He, etc. with high
gas mobilities and when gas mass is high, the phenomenon can occur by irregularly absorbing
and consuming the thermal energy generated by filaments. ( Please contact the company. )
15-3-3 There can be fluctuation of micro-currents due to serious noises from outside.
15-3-4 In the case where micro-current measurement error becomes larger due to high voltage /
high current magnetic field from neighborhood, install membranes for shielding magnetic field.
15-4 When ERr is displayed on the windows :
15-4-1 The contact between the Sensor and the Controller may be bad.
15-4-2 Sensor filament burnt out or damaged ( Please exchange the sensor. )
15-5 Set point is satisfied but alarm relay is not operating :
15-5-1 Check whether the SP1 led or SP2 led is illuminated on the front of the controller.
15-5-2 Check the Alarm high / low settings. ( ☞ Refer to ( 7-4 ) Alarm high / low setting flow )
Overloaded performance of tasks can be dangerous
Only those acknowledged in the performance ability should use the product.
Make sure to always turn off input power before any operations.
When the product has been disassembled by a user’s decision, the company or
the distributor of the product does not have any liability on quality assurance
even if effective warranty period remains.
