5. PRODUCT SPECIFICATION
5-1 Controller specification
5-2 Sensor specification
MEASURING RANGE FOR AIR AND N₂
1.0E-4 ∼ 1500 Torr
OPERATING TEMPERATURE
0 ∼ 60 ℃
STORAGE TEMPERATURE
- 40 ∼ 70 ℃
CASE MATERIAL
Aluminum
COMPLIANCE
N/A
DISPLAY
4 Digit LED , Status LED
SET POINT RELAYS
2 Point SPST ( 1A / 30VDC , 0.5A / 125VAC )
ANALOG OUTPUT
Log scale ( 0 ∼ 7.18Vdc )
Lin scale ( 0 ~ 10Vdc )
DIGITAL INTERFACE RS485 ASCII / RS485 MODBUS
POWER REQUIRED
DC24V / 200mA
WEIGHT 430g ( Included Sensor )
MOUNTING Field Flange mounting
SENSOR TYPE Wide Range Gauge ( KVC350 - XX )
SENSOR MATERIALS
Pizeo Resistive silicon Sensor with sus hosing
MEMS Pirani sensor.
INTERNAL VOLUME 5 Cm³
GAUGE BAKEOUT TEMPERATURE 150 ℃ Maximum , NON – operating
CASE MATERIALS 304 Stainless steel, borosilicate glass, Kovar
DO not use the product in explosive gas environment and at a place with combustible gas
and vapors.
DO NOT use the product to measure the pressure of explosive gas, combustible gas and
mixed gases. The temperature of SENSOR FILAMENT is generally 110 ℃ in operation.
