11-2-3 Address mapping table
11-2-3-1 Input registers
11-2-3-2 Holding registors
ADDRESS ITEM DATA
30001 (0000) Current Vacuum value LOG(Vacuum) * 1000
30002 (0001) LOG out voltage Voltage * 100
30003 (0002) LIN out voltage Voltage * 100
30004 (0003) Alarm status
0 : all off
1 : SP1 on
2 : SP2 on
3 : SP1, SP2 on
30005 (0004)
Current vacuum value 4 Byte floating point value
30006 (0005)
ADDRESS ITEM DATA
40001 (0000) Current Vacuum value LOG(Vacuum) * 1000
40002 (0001) Unit code value 0 : Torr / 1 : Pa
40003 (0002) Alarm 1 Type value 0 : H / 1 : L
40004 (0003) Alarm 2 Type value 0 : H / 1 : L
40005 (0004) Alarm 1 Log value LOG(Vacuum) * 1000
40006 (0005) Alarm 2 Log value LOG(Vacuum) * 1000
40007 (0006) Alarm 1 Dead band value 0 ~ 99
40008 (0007) Alarm 2 Dead band value 0 ~ 99
40009 (0008) Log output bias
0 : 1.0
1 : 1.0E-1
2 : 1.0E-2
3 : 1.0E-3
4 : 1.0E-4
5 : 1.0E-5
