TracVision 4-HP
Technical Manual Addendum
(ECO #7622)
The following changes apply to Revision G of the
TracVision 4-HP Technical Manual (KVH Part Number 54-0150).
4.3 TracVision 4 Field
Replaceable Units
Table 4-1 has been updated to show the new part number for the RF PCB.
FRU Part Number
Radome 02-0925-04
Main PCB 02-0992
RF PCB 02-1524
Antenna Gyro Sensor 02-1090
Antenna Gyro Gasket 24-0139
Elevation Drive Belt 24-0105-104
Elevation Motor 02-1356
LNB (North American System) 02-0870
LNB (European System) 02-1278
Data Cable 32-0619-50
†
32-0619-100
††
RF Cable 32-0417-50
†
PC Cable 32-0628-06
Power Cable 32-0510-50
Ground Cable 32-0583-50
CPU Fuses 16-0017-3150
†
North American system
††
European system
1
54-0150 Addendum to Rev. G
Table 4-1
TracVision 4 Field
Replaceable Units
