Choosing Component Locations
The major considerations in locating the TracVision components
are described below.
Cable Lengths
When determining component locations, keep in mind
accessibility and cable lengths between units. Lengths of these
cables are as follows:
Cable (Function) Length
Data Cable (Switchplate to Antenna Unit) 50 ft (15 m)
†
100 ft (30 m)
††
PC Cable (Switchplate to PC) 6 ft (2 m)
RF Cable (Antenna to IRD)* 50 ft (15 m)
†
Power Cable (Switchplate to Antenna Unit) 50 ft (15 m)
IRD Ground Cable (IRD to Switchplate) 50 ft (15 m)
†
North American system
††
European system
* Not included with European systems
Installation
54-0150
11
Table 2-4
Lengths of Provided
Belowdecks Cables
