5. Repeat Step 4 for each of the following
transponder categories:
• vertical high • vertical low
• horizontal high • horizontal low
OR
• right • left
TracVision 4 requires that the data fields for all
transponder categories be provided. If the selected
satellite does not have information for one or more of
the transponder categories, default information should
be entered in the fields as follows:
Transponder Data Default Value
Frequency 00000
Symbol Rate 27500
FEC Code the same value as provided for those
transponders with data
Network ID 0x0000
Polarity and Band whichever combinations are not
already provided
6. Type ZAP<cr> to restart the antenna.
7. If you need to configure a second user-defined
satellite, repeat this procedure starting with Step 1
to enter data for the USER2 satellite.
You have now added your user-defined satellite(s) to the
system’s satellite library.
If you want the antenna to track one or both of these user-defined
satellites, you will now need to install it. To install a satellite, use
the
SATINSTALL command, as described in ”Installing Your
Satellites” on page 35.
The next two pages provide examples of the user-defined satellite
configuration process.
54-0150
32
TracVision 4 Technical Manual
Table 2-10
Satellite Transponder
Default Data
To Next Page
