Latch with
rectangular
faceplate
Latch with
drive-in collar
exterior
interior
G (2x)
Install
deadbolt
interior.
Install
deadbolt
exterior.
Rotate torque blade to align
with D-shaped hole.
L
K
M
A
B
H (4x)
C
Make sure hole for strike
is drilled a minimum
of 1" (25 mm) deep.
B
A
B
©2015 Spectrum Brands, Inc.
WARNING: This Manufacturer advises that no lock can provide complete security by itself. This lock may be
defeated by forcible or technical means, or evaded by entry elsewhere on the property. No lock can substitute
for caution, awareness of your environment, and common sense. Builder’s hardware is available in multiple
performance grades to suit the application. In order to enhance security and reduce risk, you should consult a
qualiied locksmith or other security professional.
“UP” is on top
“UP” is on top
Retract
latch bolt.
Install
latch.
Install latch.
wood block
Extend latch bolt.
A
AQ
Q
E (2x)
Secure latch with screws.
or
Install latch
4
Install deadbolt
5
Install strike on door frame
6
Resetting SmartKey Cylinders
