KYMCO MXU 50 REVERSE - Special Tools; Lubrication Points

1. GENERAL INFORMATION
1-14
ATV 50
Item Q‘ty
Thread dia.(mm)
Torque
kgf-m (N-m,
lbf-ft)
Remarks
Front shock absorber lower mount bolt
Rear fork axle
Rear hub nut
Rear wheel shaft nut
Rear engine bracket up bolt
Rear engine bracket bolt
Engine hanger bracket bolt
2
1
4
2
1
2
1
10
14
12
32
10
10
10
4 (40, 29)
7 (70, 50)
7 (70, 50)
12 (120, 86)
4 (40, 29)
4 (40, 29)
4.5 (45, 32)
SPECIAL TOOLS
Tool Name Tool No. Memo
Flywheel puller A120E00001
Oil seal and bearing install A120E00014
Crankshaft install A120E00016
Universal holder A120E00017
Crankshaft & crankcase install A120E00024
Crankcase puller A120E00026
Crankshaft Bearing puller A120E00030
Clutch spring compressor A120E00034
Bearing puller A120E00037
Nut wrench A120F00010
LUBRICATION POINTS
ENGINE
Lubrication Points Lubricant
Crankcase sliding & movable parts
Cylinder movable parts
Transmission gear (final gear)
Kick starter spindle bushing
Drive pulley movable parts
Starter pinion movable parts
JASO-FC or API-TC
JASO-FC or API-TC
Gear oil: SAE90#
Grease
Grease
Grease
