CABLE & HARNESS ROUTING (MX’ER 50)
Throttle Cable
Rear Brake Cable
Right Front Brake Cable
Handlebar Switch Lea
d
Front Brake Cable
Left Front Brake Cable
A.C.G Wire
Starter Motor Wire
Auto Bystarter
Wi
