1. GENERAL INFORMATION
1-16
ATV 50
Sprocket hub/Rea
r
Axle Hub Collar/Oil
Seal/Bearing
Rear Brake Cam
/
Axle Hub Collar/Oil
Seal/Bearing
Driven Sprocket
Swing arm Thrust
Cove
r
