Battery remove
1. Make sure the ignition switch is OFF.
2. Remove the seat.
3. Release the rings and remove the rubber band
(1).
4. Disconnect the negative (-) terminal lead (2) from
the battery first, then disconnect the positive (+)
terminal lead (3).
5. Remove the battery.
1. Install in the reverse order of removal.
2. After installing the battery, check to see if the
battery cables are routed correctly.
Battery installation
147
(1) Rubber band
(2) Negative terminal lead
(3) Positive terminal lead
NOTE:
First connect the positive (+) cable and then
negative (-) cable to avoid short circuit.
(2)
(3)
(1)
