KYMCO MXU400 - Page 32

SPECIAL TOOLS
Engine/Transmission
A numbe
r
of special tools mus t
b
e available to the
technic
i an when performing service procedures in
this section.
This
section has been organized into sub-sections
which show a progression for the c omple te
servicing of the KYMCO ATV engine/transmission.
To service the center crankcas
e halves, the
engine/transmiss i on mus t be removed from the frame.
To
service top-side, left-side, a nd right-side compo-
n
e n t s, the engin e /transmission does no t have to be
removed from the frame.
NOTE: KYMCO recommends the use of new
gaskets, lock nuts, and seals and lubricating all
internal
components when servicing the engine/
transmission.
NOTE:
Some photog
r
aphs and illust
r
ations
used in
this section are used for clarity
purposes
only and are not designed to depict
actual
conditions.
NOTE:
Critical to
r
que specifications a
r
e located
in
Section 1.
NOTE: Special tools
a
r
e a
v
ailable f
r
om the
KYMCO Spare Parts Department.
3-2
Description p/n
Clutch Sleeve Hub Holder E017
Connecting
Rod Holder
Crankcase Separator/Crankshaft Remover E026
Magneto
Rotor Remover E073
Oil
Filter Wrench E052
Piston
Pin Puller
Side
Case Puller
Spanner
Wrench
Surface
Plate
Valve
Clearance Adjuster E012
V Blocks
