4-4
(10)
EPS Warning Indicator Light(EPS MODEL ONLY)
The EPS warning light will momentarily illuminate when the
engine starts, then goes off in one second if the system is in
order. If the warning light illuminates any other time, it indicates
the ECU or actuator has malfunctioned, or the wiring harness
has become disconnected. Stop driving immediately and see
an authorized KYMCO dealer to have the system checked
(11) Coolant Temperature Warning Indicator
When the coolant temperature reaches a specified level, this
indicator comes on to warn that the coolant temperature is too
hot. If the indicator comes on during operation, stop the engine
as soon as it is safe to do so and allow the engine to cool down
for about 10 minutes.
(12) Brake Level Warning Indicator
When the indicator light is on. Check if the fluid level is below
the MIN. level mark through the inspection window. Fill brake
fluid to MAX. level mark. The indicator light is off.
(13) Anti-Lock Brake System(ABS) Indicator Light
Meter instruments (For models equipped with ABS) the ABS
indicator light in the meter position .
This light will comes on when the ignition switch is turned on
then light is off sooner. The indicator light is normally.
If something is wrong with the ABS, the indicator comes on and
remains it. When the indicator light is on, the ABS doesn’t
function but if the ABS fails, the conventional brake system will
still work normally.
MAX
MIN
