Kyocera ECOSYS FS-3920DN User Manual

Troubleshooting 6-17
Inside the Printer
1
Open the top cover and MP tray.
2 Lift the developer unit together with the toner container out of the
printer.
3 Open the feed cover.
4 Remove the paper from the printer
If the jammed paper appears to be pinched by rollers, pull it along
the normal running direction of the paper.
5 Insert the developer unit together with the toner container, back into
the machine.
6 Close the top cover and MP tray. The printer warms up and resumes
printing.
Note If you cannot find a paper jam, try checking inside the
rear of the printer. Refer to Rear Unit on page 6-18.

Kyocera ECOSYS FS-3920DN Specifications

General

Print Technology	Laser
Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm
Memory	128 MB, expandable to 640 MB
Dimensions	390 x 285 mm
Weight	14.1 kg
