10-30
Troubleshooting > Clearing Paper Jams
Clearing Paper Jams
If a paper jam occurs, the message display will display "Paper Jam." and the machine will stop. Refer to these
procedures to remove the jammed paper.
Jam Location Indicators
If a paper jam occurs, the location of the jam will be displayed on the message display as well as the clearing instructions.
1 Shows the location of a paper jam.
2 Displays the Help screen.
For details on Help Screen, refer to the following:
Help Screen (page 2-14)
Paper Jam Location Indicator
Paper Jam Location Reference Page
A Cassette 1 page 10-31
B Cassette 2 page 10-33
C Cassette 3 page 10-35
D Multipurpose Tray page 10-37
E Inside the Machine page 10-38
F Rear Cover page 10-42
G Document Processor page 10-46
Paper
jammed in
Cassette 1.
Help
JAM****
Paper
jammed in
Cassette 1.
Help
JAM****
To Next Page
