Kyocera ECOSYS M3550idn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-3-103
1-3-2 Service mode
The machine is equipped with a maintenance function which can be used to maintain and service the
machine.
(1) Executing a service mode
Ready to copy
System Menu:
Quick Setup Wisard
Language
Report
Counter
Cassette/MP Tray Setting
Common Setting
Home
Copy
Document Box
Send
FAX
Application
Address Book/One touch
Inter net
User Login/Job Accounting
Printer
Date/Timer/Energy Saver
System/Network
Adjustment/Maintenance
Service Setting:
Test Page
Developer
FAX Country Code
FAX Call Settings
Alutitude Adjustment
MC
Memory Diagnostics
Adjustment/Maintenance:
Auto Drum Refresh
Service Setting
[Message Display]
1. Press the System Menu Key.
3. Select [
Service Setting].
4. Select the item to be set.
2. Select [Adjustment/Maintenance]
using the cursor up/down keys.
