Kyocera ECOSYS M3550idn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-6
4111 Registration sensor 2 stay jam
*2
The registration sensor 2 (RS2) does not turn off
during paper feed from cassette 1.
H
4112 The registration sensor 2 (RS2) does not turn off
during paper feed from cassette 2.
H
4113 The registration sensor 2 (RS2) does not turn off
during paper feed from cassette 3.
H
4114 The registration sensor 2 (RS2) does not turn off
during paper feed from cassette 4.
H
4115 The registration sensor 2 (RS2) does not turn off
during paper feed from cassette 5.
H
4118 The registration sensor 2 (RS2) does not turn off
during paper feed from duplex section.
H
4119 The registration sensor 2 (RS2) does not turn off
during paper feed from MP tray.
H
4201 Ejetct sensor non arrival jam The eject sensor (ES) does not turn on during
paper feed from cassette 1.
H
4202 The eject sensor (ES) does not turn on during
paper feed from cassette 2.
H
4203 The eject sensor (ES) does not turn on during
paper feed from cassette 3.
H
4204 The eject sensor (ES) does not turn on during
paper feed from cassette 4.
H
4205 The eject sensor (ES) does not turn on during
paper feed from cassette 5.
H
4208 The eject sensor (ES) does not turn on during
paper feed from duplex section.
H
4209 The eject sensor (ES) does not turn on during
paper feed from MP tray.
H
4211 Ejetct sensor stay jam The eject sensor (ES) does not turn off during
paper feed from cassette 1.
G
4212 The eject sensor (ES) does not turn off during
paper feed from cassette 2.
G
4213 The eject sensor (ES) does not turn off during
paper feed from cassette 3.
G
4214 The eject sensor (ES) does not turn off during
paper feed from cassette 4.
G
4215 The eject sensor (ES) does not turn off during
paper feed from cassette 5.
G
4218 The eject sensor (ES) does not turn off during
paper feed from duplex section.
G
4219 The eject sensor (ES) does not turn off during
paper feed from MP tray.
G
Code Contents Conditions
Jam
location*
