2NM/2NX/2NY/2NZ/2P0/2P6
1-5-50
(2) 40 ppm model
Figure 1-5-82
Figure 1-5-83
3
21
4
5
6
7
[Component formation]
1. Upper eject pulley
2. Upper eject roller
3. Actuater
(Paper full sensor (PFS))
4. LowerEject roller
5. Lower eject pulley
6. Eject upper cover
7. DU feed pulley
3
1
2
7
5
4
6
