Kyocera ECOSYS M3550idn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
2-1-12
1. Paper feed clutch (PFCL) ..................... Primary paper feed from cassette.
2. Registration clutch (RCL)...................... Controls the secondary paper feed.
3. Duplex clutch (DUCL) *2....................... Controls the drive of the duplex feed roller.
4. Middle clutch (MIDCL) *2 ...................... Controls the paper conveying at the conveying section.
5. Developer clutch (DEVCL).................... Controls the drive of the developer.
6. MP solenoid (MPSOL) .......................... Controls the MP bottom plate.
7. Faceup solenoid (FUSOL) *2................ Operates the feedshift guide.
8. Cleaning lamp (CL) ............................... Eliminates the residual electrostatic charge on the drum.
9. Fuser heater 1 (FUH1).......................... Heats the heat roller.
10. Fuser heater 2 (FUH2) *2 ..................... Heats the heat roller.
11. Fuser thermostat 1 (FUTS1) ................. Prevents overheating of the heat roller.
12. Fuser thermostat 2 (FUTS2) *2............. Prevents overheating of the heat roller.
List of correspondences of other names
*1: 40 ppm model only, *2: 50/60 ppm model only
No. Name used in service manual Name used in parts list Part.No.
1 Paper feed clutch (PFCL)
PARTS CLUTCH 20-2W Z35R
(RARTS DRIVE FEED ASSY SP)
-
(302LV94251)
2 Registration clutch (RCL)
CLUTCH 50 Z35R 302KV44041
3 Duplex clutch (DUCL) *2
PARTS CLUTCH 20-2W Z35R -
4 Middle clutch (MIDCL) *2
PARTS CLUTCH 20-2W Z35R
(RARTS DRIVE FEED ASSY SP)
-
(302LV94251)
5 Developer clutch (DEVCL)
PARTS CLUTCH 20-2W Z35R 302VL94161
6 MP solenoid (MPSOL)
SOLENOID MPF
(RARTS DRIVE FEED ASSY SP)
-
(302LV94251)
7 Faceup solenoid (FUSOL) *2 SOLENOID EXIT -
8 Cleaning lamp (CL)
P.W.BOARD ASSY ERASER
(DK-3100(U)) *1
(DK-3100(E)) *1
(DK-3100(AO)) *1
(DK-3130(U)) *2
(DK-3130(E)) *2
(DK-3130(AO)) *2
-
(302MS93042)
(302MS93022)
(302MS93052)
(302LV93062)
(302LV93042)
(302LV93072)
9 Fuser heater 1 (FH1) HEATER LAMP 120 *1
(FK-3100(U)) *1
HEATER LAMP 240 *1
(FK-3100(E)) *1
HEATER LAMP 120 *2
(FK-3130(U)) *2
HEATER LAMP 240 *2
(FK-3130(E)) *2
-
(302MS93094)
302L244030
(302MS93074)
302LV44020
(302LV93132)
302LV44031
(302LV93112)
10 Fuser heater 2 (FH2) *2
11 Fuser thermostat 1 (FTS1) THERMAL-CUTOUT 202 FUSER
(FK-3100(U)) *1
(FK-3100(E)) *1
(FK-3130(U)) *2
(FK-3130(E)) *2
-
(302MS93094)
(302MS93074)
(302LV93132)
(302LV93112)
12 Fuser thermostat 2 (FTS2) *2

Kyocera ECOSYS M3550idn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (black)	60 ppm
Scan speed (color)	40 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	250000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor model	465S
Processor family	PowerPC
Card reader integrated	No
Maximum internal memory	2048 MB
Sound power level (standby)	23.6 dB
Sound pressure level (copying)	52.6 dB
Sound pressure level (quiet mode)	49.4 dB
Paper input type	Paper tray
Total input capacity	600 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	71 W
Power consumption (PowerSave)	2.4 W
Power consumption (average operating)	777 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TUV/GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	590 mm
