Kyocera ECOSYS M3550idn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-53
(3) Connector lists
Connector Pin Signal I/O Voltage Description
YC2
1 GND - - Ground
Connected to
the LCD
2 R0 O 0/3.3 V DC LCD Control signal
3 R1 O 0/3.3 V DC LCD Control signal
4 R2 O 0/3.3 V DC LCD Control signal
5 R3 O 0/3.3 V DC LCD Control signal
6 R4 O 0/3.3 V DC LCD Control signal
7 R5 O 0/3.3 V DC LCD Control signal
8 GND - - Ground
9 G0 O 0/3.3 V DC LCD Control signal
10 G1 O 0/3.3 V DC LCD Control signal
11 G2 O 0/3.3 V DC LCD Control signal
12 G3 O 0/3.3 V DC LCD Control signal
13 G4 O 0/3.3 V DC LCD Control signal
14 G5 O 0/3.3 V DC LCD Control signal
15 GND - - Ground
16 B0 O 0/3.3 V DC LCD Control signal
17 B1 O 0/3.3 V DC LCD Control signal
18 B2 O 0/3.3 V DC LCD Control signal
19 B3 O 0/3.3 V DC LCD Control signal
20 B4 O 0/3.3 V DC LCD Control signal
21 B5 O 0/3.3 V DC LCD Control signal
22 GND - - Ground
23 DCLK O 0/3.3 V DC LCD dot clock signal
24 3.3V O 3.3V DC 3.3 V DC power output
25 3.3V O 3.3V DC 3.3 V DC power output
26 3.3V O 3.3V DC 3.3 V DC power output
27 3.3V O 3.3V DC 3.3 V DC power output
28 DE O 0/3.3 V DC(pulse) LCD data enabling signal
29 HSYNC O 0/3.3 V DC(pulse) Horizontal synchronizing signal
30 VSYNC O 0/3.3 V DC(pulse) Vertical synchronizing signal
31 LED_EN O 0/3.3 V DC Backlight LED enabling signal
32 LED_PWM O 0/3.3 V DC Backlight LED control signal
33 TSC_INT - - Not used
34 I2C_SDA - - Not used
35 I2C_SCL - - Not used

Kyocera ECOSYS M3550idn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (black)	60 ppm
Scan speed (color)	40 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	250000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor model	465S
Processor family	PowerPC
Card reader integrated	No
Maximum internal memory	2048 MB
Sound power level (standby)	23.6 dB
Sound pressure level (copying)	52.6 dB
Sound pressure level (quiet mode)	49.4 dB
Paper input type	Paper tray
Total input capacity	600 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	71 W
Power consumption (PowerSave)	2.4 W
Power consumption (average operating)	777 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TUV/GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	590 mm
