2NM/2NX/2NY/2NZ/2P0/2P6
1-3-4
FAX U600 Init All Data According to the country code and the
OEM code which were inputted, all the
softswitches, backup data, and an image
memory are initialized.
U601 Init Keep Data Softswitches other than machine data are
initialized according to the country code
and the OEM code which were inputted.
U603 User Data 1 A circuit class is set up.
U604 User Data 2 The number of times of a bell at the time of
a FAX/TEL automatic change is set up.
U605 Clr Data All the data of a communication history and
a protocol list is cleared.
U610 System Setting 1 The number of waste lines at the time of
degree, the number of waste lines at the
time of automatic reduction, and the num-
ber of waste lines at the time of automatic
reduction (A4, LETTER) are set up.
U611 System Setting 2 The number of adjustment lines at the time
of automatic reduction and the number of
adjustment lines at the time of automatic
reduction (A4, LETTER) are set up.
U612 System Setting 3 An automatic reduction setup at the time of
receiving a long manuscript is carried out.
The automatic output of a protocol list is
set up.
U620 FAX System Remote change mode (a continued type /
one shot type) is set up.
U625 Set Comm The interval of a redial and the number of
times are set up.
U630 Comm Ctrl 1 Transmitting start speed and receiving abil-
ity speed are set up.
The measure against an echo at the time
of transmission/reception is set up.
U631 Comm Ctrl 2 It is set up whether transmission and
reception can be performed in ECM.
The frequency of CED is set up.
U632 Comm Ctrl 3 It is set up whether sending out after bit33
of a DIS/DTC signal is performed.
The number of times of CNG detection at
the time of a FAX/TEL automatic change is
set up.
Section
Item
No.
Content of maintenance item Summary
To Next Page
