11-20
Appendix > Specifications
Item Description
Interface USB Interface Connector: 1 (Hi-Speed USB)
Network interface: 1 (10 BASE-T/100 BASE-TX/1000 BASE-T)
USB Port: 1 (Hi-Speed USB)
Wireless LAN support
*1
Fax: 1
*1 Only ECOSYS M5526cdw
Operating
Environment
Temperature 10 to 32.5°C/50 to 90.5°F
Humidity 10 to 80 %
Altitude 3,500 m/11,482 ft maximum
Brightness 1,500 lux maximum
Dimension (W × D × H)
(Including the Document
Processor)
16.42" × 16.89" × 19.49"
417 × 429 × 495 mm
Weight
(without toner container)
Approx. 57.33 lb/Approx. 26 kg
Space Required (W × D)
(Using multipurpose tray)
16.42" × 24.14"
417 × 613 mm
Power Source 120 V Specification Model: 120 V 60 Hz 8.6 A
230 V Specification Model: 220 to 240 V 50 Hz 4.5 A
The power consumption of the
product in networked standby (If
all network ports are connected.)
2.2W
Options
Optional Equipment (page 11-2)
To Next Page
