2PR
2-1-6
(2) Main charger unit
The main charger unit consists of the MC case, the MC roller, and the MC CLN roller, and charges the drum for image
forming.
Figure 2-1-9 Main charger unit
1
3
2
(1) MC case
(2) MC roller
(3) MC CLN roller
