Kyocera ECOSYS P7035cdn Service Manual

2PR-1
1-3-2
(2) Service mode
Service items Description
Service Status Printing a status page for service purpose
Description
Prints a status page for service purpose. The status page includes various printing settings
and service cumulative.
Purpose
To acquire the current printing environmental parameters and cumulative information.
Procedure
1. In the [Service Setting] menu, press the arrow key to select [Service Status].
2. Press the OK key. A confirmation screen appears.
3. Press [Yes] (Left select key).
[Accepted.] appears and printing begins.
Completion
Service status page (1)
Figure 1-3-1 Service status page (1)
Firmware version 2PR_2000.000.000 2013.06.07
2013/0607 15:15
[XXXXXXXX] [XXXXXXXX] [XXXXXXXX]
Service Status Page
Printer
Memory status
Standard Size
Option Slot
Total Size
Controller Information
[XXXXXXXXXXXXXXXX]
128.0 KB
128.0 KB
2.0 GB
Time
Local Time Zone
Date and Time
Time Server
+01:00 Tokio
28/07/2010 16:39
10.183.53.13
Installed Options
Paper feeder2
Paper feeder3
Paper feeder4
Memory card
SSD
UG-33
Installed
Installed
Not Installed
Installed
Installed
Installed
Ptint Coverage
Average(%)
K: 1.10
C: 2.20
M: 3.30
Y: 4.40
Period
Last Page K/C/M/Y(%)
/ Usage Page(A4/Letter Conversion)
/ 1111111.11
/ 2222222.22
/ 3333333.33
/ 4444444.44
(07/11/2005 - 07/12/2005 08:05)
1.00 / 2.22 / 3.33 / 4.44
PDF mode Y5 00
FRPO Status
User Top Margin
User Left Margin
A1+A2/100
A3+A4/100
0.00
0.00
1
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
RP Code
1234 5678 9012
5678 9012 3456
9012 3456 7890
3456 7890 1234
(71)
(72)
(73)
(74)
(1)
(7)
(8)
(9)
(10)
(11)
(12)
(19)
(21)
(22)
(20)
(15)
Paper feeder5 Not Installed
(69)
(16)
(17)
(18)
(13)
(14)
(6)
(2)
(3) (4) (5)

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
