Kyocera ECOSYS P7035cdn Service Manual

2PR
1-4-38
1-4-5 Mechanical problems
Problem Causes/check procedures Corrective measures
(1)No primary paper
feed.
Check if the surfaces of the paper feed roller,
MP paper feed roller are dirty with paper pow-
der.
Clean with isopropyl alcohol.
Check if the paper feed roller, MP paper feed
roller are deformed.
Check visually and replace any deformed
rollers (See page 1-5-8 and 1-5-11).
Defective paper feed clutch installation. Check visually and remedy if necessary.
(2)No secondary paper
feed.
Check if the surfaces of the upper and lower
registration rollers are dirty with paper pow-
der.
Clean with isopropyl alcohol.
Defective registration clutch installation. Check visually and remedy if necessary.
(3)Skewed paper feed. Width guide in a cassette installed incorrectly. Check the width guide visually and correct
or replace if necessary.
Deformed width guide in a cassette. Repair or replace if necessary.
Defective MP tray slider installation. Check the slider visually and correct or
replace if necessary.
Deformed MP tray slider. Check visually and replace any deformed
slider.
(4)Multiple sheets of
paper are fed at one
time.
Check if the paper is curled. Replace the paper.
Paper is not placed correctly in the cassette. Set the paper correctly.
Check if the retard roller is worn. Replace the retard roller pulley if it is worn.
Check if the separator pad or MPF separation
pad (duplex model only) is worn.
Replace the separator pad if it is worn (See
page 1-5-11).
(5)Paper jams. Check if the paper is excessively curled. Replace the paper.
Check if the contact between the front and
rear registration rollers is correct.
Check visually and remedy if necessary.
Check if the heat roller or press roller is
extremely dirty or deformed.
Replace the fuser unit (See page 1-5-24).
(6)Toner drops on the
paper conveying path.
Check if the drum unit or developing unit is
extremely dirty.
Clean the drum unit or developing unit.
(7)Abnormal noise is
heard.
Check if the pulleys, rollers and gears operate
smoothly.
Grease the bearings and gears.
Check if the following electromagnetic
clutches are installed correctly:
Check visually and remedy if necessary.

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
