Kyocera ECOSYS P7035cdn Service Manual

2PR
1-4-16
6000 Broken fuser heater lamp 1 wire
The detected fuser thermistor 1 temper-
ature does not rise 1
C/1.8F after the
fuser heater lamp 1 has been turned on
continuously for 10 seconds in warming
up.
The fuser temperature does not reach
100
C/212F after the fuser heater lamp
1 has been turned on continuously for 40
seconds in warming up.
The detected temperature of fuser
thermistor 2 does not reach the specified
temperature (ready indication tempera-
ture) after fuser heater lamp 1 has been
turned on continuously for 90 seconds in
warming up.
The detected temperature of fuser
thermistor 2 does not rise 1
C/1.8F
after fuser heater lamp 1 has been
turned on continuously for 10 seconds
during printing.
The detected temperature of fuser
thermistor 2 is 120
C/248F or less con-
tinuously for 3 seconds during printing.
The detected temperature of fuser
thermistor 2 is 100C/180F lower than
the detected temperature of fuser therm-
istor 1 continuously for 3 seconds.
Defective harness
between fuser
thermistor 2 and
paper exit PWB
(YC5), or improper
connector inser-
tion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective harness
between paper exit
PWB (YC1) and
engine PWB
(YC602), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Fuser thermistor 2
installed incor-
rectly.
Replace the fuser unit (See page 1-5-24).
Fuser thermal cut-
out triggered.
Replace the fuser unit (See page 1-5-24).
Fuser heater lamp
1 installed incor-
rectly.
Replace the fuser unit (See page 1-5-24).
Broken fuser
heater lamp 1 wire.
Replace the fuser unit (See page 1-5-24).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
28).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
