Kyocera ECOSYS P7035cdn Service Manual

2PR
1-4-37
(12)A paper jam in
the paper feed sec-
tion, paper conveying
section, fuser sec-
tion or duplex section
is indicated when the
power switch is
turned on.
A piece of paper torn from
copy paper is caught
around registration switch,
duplex conveying sensor or
paper exit sensor.
Check and remove if any.
Defective registration sen-
sor or duplex conveying
sensor.
Replace the registration sensor or duplex conveying sensor.
Defective paper exit sensor. Replace the paper exit PWB.
Defective engine PWB. Replace the engine PWB (See page 1-5-28).
(13)The message
requesting front
cover to be closed is
displayed when the
front cover is closed.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Front cover open/close switch - Paper exit PWB (YC6)
Paper exit PWB (YC1) - Engine PWB (YC602)
Defective front cover open/
close switch.
Replace the front cover open/close switch.
Defective paper exit PWB. Replace the paper exit PWB.
Defective engine PWB. Replace the engine PWB (See page 1-5-28).
(14)The message
requesting cover to
be closed is dis-
played when the top
cover is closed.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Interlock switch - Engine PWB (YC13)
Defective interlock switch. Replace the interlock switch.
Defective engine PWB. Replace the engine PWB (See page 1-5-28).
(15)The message
requesting left cover
to be closed is dis-
played when the left
cover is closed.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Left cover switch - Engine PWB (YC14)
Defective left cover switch. Replace the left cover switch.
Defective engine PWB. Replace the engine PWB (See page 1-5-28).
(16)Defective waste
toner box detecting.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Waste toner full sensor - Engine PWB (YC12)
Defective waste toner full
sensor.
Replace the waste toner full sensor.
Defective engine PWB. Replace the engine PWB (See page 1-5-28).
(17)Others. Wiring is broken, shorted or
makes poor contact.
Check for continuity. If none, repair.
Problem Causes Check procedures/corrective measures

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
