Kyocera ECOSYS P7035cdn Service Manual

2PR
1-4-36
(5)MP paper feed
solenoid, ID solenoid,
duplex solenoid do
not operate.
Broken solenoid coil. Check for continuity across the coil. If none, replace the solenoid.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
MP paper feed solenoid - Engine PWB (YC40)
ID solenoid - Engine PWB (YC617)
Duplex solenoid - Engine PWB (YC3)
Defective engine PWB. Replace the engine PWB (See page 1-5-28).
(6)Main charging is
not performed.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the high voltage PWB
1 (See page 1-5-34).
High voltage PWB 1 - Engine PWB (YC600)
Defective main charger unit Replace the main charger unit (See page 1-5-15).
Defective high voltage PWB
1.
Replace the high voltage PWB 1 (See page 1-5-34).
Defective engine PWB. Replace the engine PWB (See page 1-5-28).
(7)No developing
bias is output.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the high voltage PWB
1 (See page 1-5-34).
High voltage PWB 1 - Engine PWB (YC600)
Defective high voltage PWB
1.
Replace the high voltage PWB 1 (See page 1-5-34).
Defective engine PWB. Replace the engine PWB (See page 1-5-28).
(8)Transfer charging
is not performed.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the high voltage PWB
2 (See page 1-5-41).
High voltage PWB 2 - Engine PWB (YC610)
Defective high voltage PWB
2.
Replace the high voltage PWB 2 (See page 1-5-41).
Defective engine PWB. Replace the engine PWB (See page 1-5-28).
(9)The message
requesting paper to
be loaded is shown
when paper is pres-
ent in the cassette.
Defective paper sensor 1/2. Replace the engine PWB (See page 1-5-28).
Broken paper sensor 1/2
actuator.
Check the bending of the actuator lever of the paper sensor 1/2 if
there is trouble, remedy or replace.
Defective engine PWB. Replace the engine PWB (See page 1-5-28).
(10)The message
requesting paper to
be loaded is shown
when paper is pres-
ent in the MP tray.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
MP tray sensor - Engine PWB (YC21)
Defective MP tray sensor. Replace the MP tray sensor.
Defective engine PWB. Replace the engine PWB (See page 1-5-28).
(11)The size of paper
in the cassette is not
displayed correctly.
Defective harness or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Cassette size switch - Engine PWB (YC9)
Defective cassette size
switch.
Replace the cassette size switch.
Defective engine PWB. Replace the engine PWB (See page 1-5-28).
Problem Causes Check procedures/corrective measures

Kyocera ECOSYS P7035cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	150000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2650 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	33.7 dB
Sound pressure level (printing)	53.2 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	86 W
Power consumption (printing)	622 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	512 mm
