2PR-1
2-4-3
(2) Repetitive defects gauge
*: The repetitive marks interval may vary depending on operating conditions.
31 mm
(1 1/4")
Rear registration roller
First occurrence of defect
50 mm
(1 15/16")
Front registration roller
63 mm
(2 1/2")
Developing roller (Developing unit)
65 mm
(2 9/16")
Transfer roller
79 mm
(3 1/8")
Press roller (Fuser unit)
94 mm
(3 3/8")
Drum (Drum unit)
94 mm
(3 3/8")
Heat roller (Fuser unit)
To Next Page
