Kyocera ECOSYS P7035cdn Service Manual

2PR
1-3-14
Service items Description
No. Items Description
(7)
cont.
Paper
Jam
Log
# Count. Event
Remembers 1 to 16 of occurrence.
If the occurrence of the previous
paper jam is less than 16, all of the
paper jams are logged. When the
occurrence excessed 16, the old-
est occurrence is removed.
The total page
count at the time
of the paper
jam.
Log code (2 digit, hexadecimal, 5 cate-
gories)
(a) Cause of a paper jam
(b) Paper source
(c) Paper size
(d) Paper type
(e) Paper exit
(a) Cause of paper jam
0105: Registration sensor not detected [-]
0110: Top tray open [-]
0111: Rear cover open [-]
0112: Front cover open [-]
0501: No paper feed from cassette 1 [1]
0502: No paper feed from cassette 2 [2]
0503: No paper feed from cassette 3 [3]
0504: No paper feed from cassette 4 [4]
0505: No paper feed from cassette 5 [5]
0508: No paper feed from duplex section [I]
0511: Multiple sheets in cassette 1 [1]
0518: Multiple sheets in duplex section [I]
1403: PF feed sensor 1 does not turn ON (Paper feeder 2) [2]
1404: PF feed sensor 1 does not turn ON (Paper feeder 3) [2]
1405: PF feed sensor 1 does not turn ON (Paper feeder 4) [2]
1420: PF feed sensor 1 is turned ON [2]
1604: PF feed sensor 2 does not turn ON (Paper feeder 3) [3]
1605: PF feed sensor 2 does not turn ON (Paper feeder 4) [3]
1620: PF feed sensor 2 is turned ON [3]
1805: PF feed sensor 3 does not turn ON (Paper feeder 4) [4]
1820: PF feed sensor 3 is turned ON [4]
2020: PF feed sensor 4 is turned ON [5]
4002: Registration sensor does not turn ON (Paper feeder 1) [1]
4003: Registration sensor does not turn ON (Paper feeder 2) [1]
4004: Registration sensor does not turn ON (Paper feeder 3) [1]
4005: Registration sensor does not turn ON (Paper feeder 4) [1]
4009: Registration sensor does not turn ON (MP tray) [1]
4012: Registration sensor does not turn OFF (Paper feeder 1) [H]
4013: Registration sensor does not turn OFF (Paper feeder 2) [H]
4014: Registration sensor does not turn OFF (Paper feeder 3) [H]
4015: Registration sensor does not turn OFF (Paper feeder 4) [H]
4019: Registration sensor does not turn OFF (MP tray) [H]
4020: Registration sensor is turned ON [H]
