Service items Description
No. Items Description
(7)
cont.
Paper
Jam
Log
Jam location
Figure 1-3-7Jam location








[B]
[H]
[G]
[ I ]
[1]
[2]
[3]
[4]
[5]
Cassette 1
MP tray
Printer
Paper feeder 1
(Cassette 2)
Paper feeder 2
(Cassette 3)
Paper feeder 3
(Cassette 4)
Paper feeder 4
(Cassette 5)
 Registration sensor
 Paper exit sensor
 Duplex conveying sensor
 Paper full sensor
 PF paper feed sensor
Sensors
[B] MP tray
[1] Cassette 1 (printer)
[2] Paper feeder 1
[3] Paper feeder 2
[4] Paper feeder 3
[5] Paper feeder 4
[H] Printer inside
[G] Paper exit section
[ I ] Duplex section
Paper jam location
