Kyocera FS-1120D User Manual

3-4 Connecting and Printing
Express Mode
In Express Mode, the installer automatically detects the printer when
it is turned on. Use Express Mode for standard connection methods.
1 In the installation method selection window, select Express Mode.
The print system detection window appears and the installer detects
the connected printers. If the installer does not detect a print system,
check that the print system is connected via USB or a network and
that it is turned on. Then click Refresh to search print system again.
2 Select the printer you want to be installed, and click Next.
3 You can customize the print system name in the installation settings
window. This will be the name displayed in the Printer window and in
the printer lists displayed in applications. Specify whether to share
the print system name or set the print system as an existing printer
and then click Next.
4 A window appears in which you can check the settings. Check the
settings carefully and then click Install.
5 A message appears saying that the printer has been installed
successfully. Click Finish to exit the printer installation wizard and
return the CD-ROM main menu.
If the device setup dialog box appears after you click Finish, you
can specify the settings for items such as optional features installed
in the print system. You can also specify the device settings after you
exit the installation. For details, refer to Device Settings in the printer
driver operation manual on the CD-ROM.
This completes the printer driver installation procedure. Follow the
on-screen instructions to restart the system, if required.
Note While the information shown in Windows Vista and
Windows 7/Windows XP installation dialog boxes differs
slightly, the installation procedure is the same.
Note If the Found New Hardware Wizard appears, click
Cancel. If a hardware installation warning message appear,
click Continue.
IMPORTANT Step 3 only appears if the print system is
connected via a network. It does not appear if the print system is
connected via a USB at the time of the first installation.
Note If the Windows security window appears, click Install
this driver software anyway.

Kyocera FS-1120D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Memory type	DDR
Memory slots	1
Processor model	405F5
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Sound pressure level (quiet mode)	49 dB
Total input capacity	300 sheets
Maximum input capacity	550 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Mobile printing technologies	Not supported
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.3 W
Power consumption (printing)	525 W
Power consumption (PowerSave)	4.4 W
Certification	GS, TUV, CE
Product color	Black, White
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Printing colors	Black
Maximum duty cycle	20000 pages per month
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PJL, PostScript 3
Standard interfaces	USB 2.0
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	250 mm
