2-48 Using the Operation Panel
RAM Disk Mode (Using the RAM disk)
The RAM disk is a memory space shared within the printer memory that
can temporarily store print jobs. The stored print job can then be used to
print multiple copies of the job reducing the total amount of time required
to print the whole job.
To use the RAM disk, activate and enter the desired size of the RAM disk
in the manner described below. The maximum RAM disk size can be
calculated as follows:
When the RAM disk is activated = The maximum RAM disk size is 4MB
(when no options are attached)
When the optional memory is installed = The maximum RAM disk size is
1/2 of the total optional memory installed
To activate RAM disk in the printer's memory, first you must set the RAM
disk mode to On and set the desired data size for the RAM disk as
described in the following section. This allows you to perform the
following operations on the RAM disk.
1 Press Z while Device Common > is displayed.
2 Press U or V repeatedly until >RAM Disk Mode > appears.
3 Press [OK]. A blinking question mark (?) appears.
4 Select On or Off using U or V.
5 Press [OK].
6 Press [MENU]. The display returns to Ready.
Note The printer also supports CF card as a storage device. The
CF card is installed into the dedicated slot of the printer. The RAM
disk is an allocated part of the printer’s memory.
IMPORTANT The RAM disk stores data only temporarily. When the
printer is reset or turned off, the stored data will be erased.
The RAM disk is allocated from the printer memory available to users.
If the size of the RAM disk is set too large, the printing speed may
decrease or the memory may become insufficient.
>RAM Disk Mode
? Off

Table of Contents

Other manuals for Kyocera FS-1370DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera FS-1370DN and is the answer not in the manual?

Kyocera FS-1370DN Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)7 s
Print speed (black, normal quality, A4/US Letter)35 ppm
Memory typeDDR
Memory slots1
Processor model440F5
Processor familyPowerPC
Maximum internal memory1152 MB
Sound power level (standby)30 dB
Sound pressure level (printing)55 dB
Sound pressure level (quiet mode)49 dB
Total input capacity300 sheets
Maximum input capacity800 sheets
Total number of input trays2
Maximum number of input trays4
Multi-Purpose tray input capacity50 sheets
Mobile printing technologiesNot supported
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)11 W
Power consumption (printing)554 W
Power consumption (PowerSave)5.5 W
Printing colorsBlack
Maximum duty cycle50000 pages per month
Recommended duty cycle2800 pages per month
Page description languagesEpson LQ, IBM ProPrinter, PCL 5e, PCL 6, PJL, PostScript 3
DisplayLCD
CertificationGS, TUV, CE
Product colorBlack, White
Custom media width70 - 215.9 mm
Maximum print size216 x 356 mm
Custom media length148 - 356 mm
Duplex media weight60 - 105 g/m²
Paper tray media typesPlain paper
Paper tray media weight60 - 120 g/m²
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 220 g/m²
Standard interfacesEthernet, USB 2.0
Server operating systems supportedWindows 2000 Advanced Server, Windows 2000 Server, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth393 mm
Width375 mm
Height267 mm
