Page #128 background imageLoading...
Page #128 background image
Operation Panel
4-66
2 Press [OK]. The PIN code entry screen appears.
3 Enter the PIN Code using the numeric keys.
4 Press [OK]. The message Connecting... appears and the
connection with the access point starts.
Custom Setup (Detailed settings for the wireless network)
It is possible to change the detailed settings of the wireless network.
1 In the Wireless Network menu, press U or V to select Custom
Setup.
2 Press [OK]. The Custom Setup menu screen appears.
The following operations are possible:
Netwk Name (SSID) (Registration of the access point's SSID)
Connection mode (Switch between connection modes)
Channel (Channel settings)
Netwk Authentic. (Network Authentication setting)
Encryption (Encryption settings)
Netwk Name (SSID) (Registration of the access point's SSID)
This sets the SSID (Service Set Identifier) for the wireless network access point the machine will be connected to.
1 In the Custom Setup menu, press U or V to select Netwk
Name(SSID).
2 Press [OK]. The Netwk Name(SSID) entry screen appears.
3 Enter the access point's SSID using the numeric keys.
4 Press [OK]. The Custom Setup menu reappears.
Connection mode (Switch between connection modes)
This selects the method for connecting to the wireless network. Set Ad Hoc when machines will be connected directly with
each other, without going through an access point.
1 In the Custom Setup menu, press U or V to select Connection
Mode.
2 Press [OK]. The Connection Mode screen appears.
The available Connection Mode are as follows:
Ad Hoc (Connect without going through access points)
Infrastructure (Connect via an access point)
Note Up to 8 characters can be entered. For details on
entering characters, refer to Character Entry Method on page
A-2.
PIN Code:
a
b
*
S
ABC
[ Text ]
Custom Setup:
a
b
********************-
2
Connection Mode
3
Channel
[ Exit ]
Note Up to 32 characters can be entered. For details on
entering characters, refer to Character Entry Method on page
A-2.
Netwk Name(SSID):
a
b
*
S
ABC
[ Text ]
Connection Mode:
a
b
1
Ad Hoc
********************-
