Kyocera FS-4100DN User Manual

4-113
Operation Panel
3 Enter the port number using the numeric keys.
4 Press [OK]. The port number is registered and the Netwk Auth.
Set menu reappears.
Domain Name (Entering of Domain Name)
Enter the domain name for the authentication server.
1 In the Netwk Auth. Set menu, press U or V to select Domain
Name.
2 Press [OK]. The Domain Name screen appears.
3 Enter the domain name using the numeric keys.
4 Press [OK]. The domain name is registered and the Netwk Auth.
Set menu reappears.
NW User Property (Obtain the network user property)
This setting is to acquire user information from the LDAP server.
1 In the User Login Set. menu, press U or V to select NW User
Property.
2 Press [OK]. The NW User Property menu screen appears.
The options available in NW User Property are as follows:
• Off/On (Switching network user property acquisition On/Off)...4-
113
• Authenticat Type (Authenticat type setting)...4-114
Off/On (Switching network user property acquisition On/Off)
Set the NW User Property to On/Off.
1 In the NW User Property menu, press U or V to select Off/On.
Note If the port number is registered as a blank field, the
default port number will be enabled.
Note This setting is only displayed when NTLM or Kerberos has been set as the Server Type (Server type
selection) on page 4-112.
Note Up to 256 characters can be entered. For details on
entering characters, refer to Character Entry Method on page
A-2.
Domain Name: a b
*
ABC
[ Text ]
Note This setting is only displayed when Netwk Authentic. has been set as the Login Type (Enabling of User
Login Administration) on page 4-111 and NTLM or Kerberos has been set as the Server Type (Server type
selection) on page 4-112.
Note Authenticat Type is only displayed when
Kerberos has been set as the Server Type (Server type
selection) on page 4-112.
NW User Property: a b
********************-
2 Authenticat Type
[ Exit ]
1 Off/On

Kyocera FS-4100DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Mobile printing technologies	-
PCL fonts	93
Printer fonts	Bitmap, PCL, PostScript
Maximum duty cycle	200.000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Processor model	465
Processor family	PowerPC
Maximum internal memory	1280 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Total input capacity	600 sheets
Total output capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Parallel, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	13.3 W
Power consumption (printing)	618 W
Power consumption (PowerSave)	1.6 W
Display	LCD
Certification	GS, TÜV, CE
Product color	Black, White
Media thickness	0.11 mm
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
Dimensions (WxDxH)	380 x 416 x 320 mm
