Page #210 background imageLoading...
Page #210 background image
Document Box
5-16
File operations (Printing, deleting and moving files)
It is possible to print files stored in a Custom Box, to delete them or to move them to a different Custom Box.
The following operations are possible:
Box number/Box name (Select a File)...5-16
Select/Deselect All Files...5-16
Print a File...5-17
Print a File (Changes to the print settings)...5-18
Delete a File...5-22
Moving files...5-22
Check File Details...5-23
1 In the Custom Box list screen, press U or V to select a Custom Box.
2 Press [OK]. The printer displays a list of files stored in the Custom
Box.
Box number/Box name (Select a File)
To print/delete a file in the Custom Box, first select the file to be printed or deleted.
1 Press U or V to select the file to be printed/deleted.
2 When [Select] ([Right Select]) is pressed, the file is selected. A
checkmark will be placed on the right of the selected file.
Select the checkmarked file and press [Select] ([Right Select])
again to cancel the selection.
Select/Deselect All Files
All files in the Custom Box are selected.
1 In the file list screen, press U or V to select All Files.
Note If the screen for entering a password is displayed then
enter the password using the numeric keys and then press [OK].
Refer to Character Entry Method on page A-2 for details on
entering characters.
Custom Box:
a
b
********************-
i
0002 XYZ box
i
0003 Common
[ Menu ] [ Add ]
m
0001 ABC box:
a
b
********************-
j
AAAA
g
j
BBBB
g
[ Menu ] [ Select ]
Note To select all files, follow the steps of Select/Deselect All
Files on page 5-16.
m
0001 ABC box:
a
b
********************-
j
AAAA
g
j
BBBB
g
[ Menu ] [ Select ]
m
0001 ABC box:
a
b
********************-
j
AAAA
T
j
BBBB
T
[ Menu ] [ Select ]
