Kyocera FS-4100DN User Manual

Troubleshooting
8-14
The data transferred to the printer was too complex to print on a page. Press
[OK] to resume printing.
A RAM disk error has occurred. Look at the error code given in place of ##.
The possible error codes and their descriptions are as follows.
02: RAM Disk Mode is set to Off. Set the setting to On. Refer to RAM Disk
Mode (Setting the RAM disk) on page 4-82.
03: The RAM disk is write protected using command operation. Remove the
write protection using the command.
04: No disk space. Purge unnecessary files or increase the RAM disk size. For
more information, refer to RAM Disk Size (RAM disk size setting) on page 4-82.
05: The desired file does not exist in the RAM disk. Stored the file in the RAM
disk.
10: The file stored in the RAM disk is write protected using command operation.
Remove the write protection using the command.
There are already 100 accounts registered so it is not possible to register any
new accounts.
Replace Maintenance Kit which is displayed on the message display.
Replacement of the maintenance kit is necessary at every 500,000 images of
printing (or every 300,000 images on FS-2100D/FS-2100DN) and requires
professional servicing.
Toner has run out in the toner container. Replace the toner container using a
new toner kit. The printer does not operate when this message is displayed.
This message is displayed when printing was attempted, despite the Job
Account function being on with Restriction applied as the job limit for each job
account.
To return the printer to the print-ready status, press [OK].
For more information, refer to Job Account.Set. (Job Account setting) on page
4-120.
Message Corrective Action
Print overrun.
RAM disk error.
Press [OK].
##
Registered numbers
exceeded.
Cannot add.
Replace MK.
Replace the toner.
Restricted by
Job Accounting.
Press [OK].

Kyocera FS-4100DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Mobile printing technologies	-
PCL fonts	93
Printer fonts	Bitmap, PCL, PostScript
Maximum duty cycle	200.000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PDF 1.7, PostScript 3
Processor model	465
Processor family	PowerPC
Maximum internal memory	1280 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Total input capacity	600 sheets
Total output capacity	500 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Parallel, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	13.3 W
Power consumption (printing)	618 W
Power consumption (PowerSave)	1.6 W
Display	LCD
Certification	GS, TÜV, CE
Product color	Black, White
Media thickness	0.11 mm
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
Dimensions (WxDxH)	380 x 416 x 320 mm
