Operation Panel
4-72
MACAddressFilter (MAC address filtering setting)
This sets whether or not to enable MAC address filtering.
1 In the Basic menu, press U or V to select MACAddressFilter.
2 Press [OK]. The MACAddressFilter screen appears.
3 Press U or V to select whether MAC address filtering is enabled.
4 Press [OK]. The MAC address filtering setting is set and the Basic
menu reappears.
Restart Network (Restarting the optional network interface kit)
After all network related settings have been done, restart the network card of the device. This is mandatory to make the
settings effective.
1 In the Basic menu, press U or V to select Restart Network.
2 Press [OK]. A confirmation screen appears.
3 Press [Yes] ([Left Select]). The message Restarting...
appears and the network is restarted.
Pressing [No] ([Right Select]) returns to the Basic menu without
restarting the network.
Communication (Select the network interface to use)
The client function such as the network authentication and the reference of user information via LDAP operates only by the
selected interface. This function is mainly used for the network system administrator. For more information about each
function, refer to Command Center RX User Guide and IB-50/IB-51 User’s Manual.
1 In the Optional Network menu, press U or V to select
Communication.
2 Press [OK]. The Communication screen appears.
Note The detailed settings for MAC address filtering are selected using the optional network interface kit utility
software.
To Next Page
