Kyocera FS-4300DN User Manual

Operation Panel
4-40
1 In the Print Settings menu, press U or V to select MP Tray
Priority.
2 Press [OK]. The MP Tray Priority screen appears showing the
available MP tray priority mode options.
Off (The printer driver settings are followed.)
Auto Feed (If Auto is selected in the printer driver and there is paper
in the MP tray then the paper feed will be from the MP tray.)
Always (If there is paper in the MP tray then the paper feed will be
from the MP tray regardless of what is set in the printer driver.)
3 Press U or V to select the desired MP tray priority mode.
4 Press [OK]. The MP tray priority mode is set and the Print
Settings menu reappears.
Paper Feed Mode (Setting the paper feed source)
This mode specifies how the paper should be fed once the paper feed source and paper type have been chosen. If Auto
is selected, the printer searches for a paper feed source that matches the paper size and type, and paper is then delivered
from that source. If Fixed is selected and there is no matching paper feed source, handling proceeds as specified by Paper
Mismatch for Error Handling. For details on paper feeding when Fixed is selected, refer to Paper Mismatch (Detection
settings for paper size/type errors when the paper source is fixed) on page 4-85. The default setting is Auto. To change the
settings, follow the steps described below.
1 In the Print Settings menu, press U or V to select Paper Feed
Mode.
2 Press [OK]. The Paper Feed Mode screen appears showing the
available paper feed options.
3 Press U or V to select the desired paper feed mode.
4 Press [OK]. The paper feed mode is set and the Print Settings
menu reappears.
When the Paper Runs Out During Printing
When Paper Feed Mode is set to Fixed, if the paper in the cassette runs out during printing, Load paper in cassette
1. is displayed and the printer stands by. In this event, either replenish the paper in the empty cassette or use the procedure
below to print from another paper source.
1 While Load paper in cassette 1. is displayed, press [Alt.]
([Left Select]). The Alternative menu screen appears.
2 Press U or V to select the desired paper feed source and paper size.
3 Press [OK]. Printing continues.
MP Tray Priority: a b
********************-
2 Auto Feed
3 Always
1 *Off
Paper Feed Mode: a b
********************-
2 Fixed
1 *Auto
Alternative: a b
********************-
C A4 Preprint
D B5 Plain
B A5 Plain

Kyocera FS-4300DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	60 ppm
Mobile printing technologies	Not supported
Printing colors	Black
Maximum duty cycle	275000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor model	465
Processor family	PowerPC
Compatible memory cards	SD, SDHC
Maximum internal memory	1280 MB
Sound power level (standby)	27.4 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	600 sheets
Total output capacity	500 sheets
Maximum input capacity	2600 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows MultiPoint Server 2011, Windows SBS 2011 Essentials, Windows SBS 2011 Standard, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	13.1 W
Power consumption (printing)	757 W
Power consumption (PowerSave)	1.6 W
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
