Kyocera FS-6970DN Operation Guide

i
Contents
1 Machine Parts ............................................................................. 1-1
Components at the Front of the Printer ................................... 1-2
Components at the Left of the Printer and
Internal Components .................................................................. 1-2
Components at the Rear of the Printer ..................................... 1-3
Operation Panel .......................................................................... 1-4
2 Loading Paper ............................................................................. 2-1
Loading Paper into the Cassette ............................................... 2-2
Loading Paper into MP (Multi-Purpose) Tray ........................... 2-5
3 Connecting and Printing ............................................................ 3-1
Connections ................................................................................ 3-2
Changing Network Interface Parameters ................................. 3-4
Printing a Network Interface Status Page .............................. 3-12
Installing the Printer Driver ..................................................... 3-13
Printing from Application Software ........................................ 3-20
Status Monitor .......................................................................... 3-21
Uninstalling Software (Windows PC) ...................................... 3-25
4 Maintenance ................................................................................ 4-1
General Information ................................................................... 4-2
Toner Container Replacement .................................................. 4-2
Cleaning the Printer ................................................................... 4-7
Prolonged Non-Use and Moving of the Printer ........................ 4-8
5 Troubleshooting ......................................................................... 5-1
General Guidelines ..................................................................... 5-2
Print Quality Problems ............................................................... 5-3
Error Messages ........................................................................... 5-5
Ready, Data, and Attention Indicators .................................... 5-10
Clearing Paper Jams ................................................................ 5-11
6 Appendix ..................................................................................... 6-1
Specifications ............................................................................. 6-2
Environmental Standard Requirements ................................... 6-4
Index .................................................................................... Index-1

Kyocera FS-6970DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Processor model	440
Processor family	PowerPC
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	51 dB
Power requirements	AC 220-240 V, 50/60 Hz
Total input capacity	350 sheets
Total output capacity	250 sheets
Maximum input capacity	1350 sheets
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 450 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Ledger (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 220 g/m²
Security algorithms	802.1x RADIUS, SSL/TLS
Mobile printing technologies	Not supported
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.6 W
Power consumption (printing)	516 W
Power consumption (PowerSave)	6.3 W
Certification	GS, TÜV, CE
Product color	Black, Grey
Printing colors	Black
Maximum duty cycle	150000 pages per month
Recommended duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PostScript 3
Standard interfaces	Ethernet, Parallel, USB 2.0
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	469 x 395 x 285 mm
