Using the Operator Panel
ADVANCED OPERATION GUIDE 2-65
2
When the unit of measurement is set, press
V.
>>X Dimension appears (the paper width
setting).
3
Press [OK] ([ENTER]). A blinking cursor (_)
appears.
4
Press U or V to increase or decrease the value of the figure where the
cursor is blinking and display the desired width. The width can be set
between 148 and 216 mm (5.83 to 8.5 inches). You can use Y or Z to
move the cursor right and left.
5
Display the paper width and press [OK] ([ENTER]).
6
When the width is set, press. >>Y Dimension appears (the paper length
setting). Set the desired length in the same way as the width. The length
can be set between 210 and 356 mm (8.27 to 14.02 inches).
7
Display the paper length, press [OK] ([ENTER]).
8
Press [MENU]. The display returns to Ready.
9
To print using the custom size set above, define the same custom size on
the printer driver. For details, see KX Printer Drivers Operation Guide.
Setting the Cassette Paper Type
By setting a paper type (plain, recycled, etc.) for the paper cassette, you
can automatically select the paper in the paper cassette according to the
paper type you command on the printer driver. The default setting is plain
paper for all paper cassettes.
For more information about paper types that you can feed from the paper
cassette, see Paper Specifications on page 1-2.
1
Press [MENU].
2
Press U or V repeatedly until Paper
Handling > appears.
3
Press Z.
4
Press U or V repeatedly until >Cassette Type appears.
If optional paper feeders are added,
Cassette 1 Type will appear for the
standard paper cassette and Cassette 2
>>X Dimension
216 mm
>>X Dimension
216
mm
Paper Handling >
>Cassette Type
Plain
To Next Page
