2FB/2FC
2-3-39
YC5 A1 LIFT3 ESW 2 I 0/5 V DC Cassette 3 paper empty detection signal
Connected
to lift motor
3/4, paper
length size
switch 1/2,
feed switch
3/4/5
A2 SGND - - Signal ground
A3 LIFT3 ESW 1 I 0/5 V DC Cassette 3 paper empty detection signal
A4 LIFT MOT3 L O 0/24 V DC Lift motor 3: On/off
A5 LIFT MOT3 H O 0/24 V DC Lift motor 3: On/off
A6 LIFT4 ESW 2 I 0/5 V DC Cassette 4 paper empty detection signal
A7 SGND - - Signal ground
A8 LIFT4 ESW 1 I 0/5 V DC Cassette 4 paper empty detection signal
A9 LIFT MOT4 L O 0/24 V DC Lift motor 4: On/off
A10 LIFT MOT4 H O 0/24 V DC Lift motor 4: On/off
A11 SGND - - Signal ground
A12 PSD SW3 I 0/5 V DC Paper length size switch 1: On/off
B1 N.C - - Not used
B2 SGND - - Signal ground
B3 PSD SW4 I 0/5 V DC Paper length size switch 2: On/off
B4 SGND - - Signal ground
B5 FSW C I 0/5 V DC Feed switch 3: On/off
B6 5V O 5 V DC 5 V DC power output
B7 SGND - - Signal ground
B8 FSW D I 0/5 V DC Feed switch 4: On/off
B9 5V O 5 V DC 5 V DC power output
B10 SGND - - Signal ground
B11 FSW E I 0/5 V DC Feed switch 5: On/off
B12 5V O 5 V DC 5 V DC power output
YC6
1 VF MOT/A O 0/24 V DC
(pulse)
Vertical feed motor drive signal
Connected
to the verti-
cal feed
motor, paper
feed motor
3/4
2 24V O 24 V DC 24 V DC power output
3 VF MOT A O 0/24 V DC
(pulse)
Vertical feed motor drive signal
4 VF MOT B O 0/24 V DC
(pulse)
Vertical feed motor drive signal
5 24V O 24 V DC 24 V DC power output
6 VF MOT/B O 0/24 V DC
(pulse)
Vertical feed motor drive signal
7 PF MOT4 A O 0/24 V DC
(pulse)
Paper feed motor 4 drive signal
8 PF MOT4 B O 0/24 V DC
(pulse)
Paper feed motor 4 drive signal
9 PF MOT4/A O 0/24 V DC
(pulse)
Paper feed motor 4 drive signal
10 PF MOT4/B O 0/24 V DC
(pulse)
Paper feed motor 4 drive signal
11 PF MOT3 A O 0/24 V DC
(pulse)
Paper feed motor 3 drive signal
12 PF MOT3 B O 0/24 V DC
(pulse)
Paper feed motor 3 drive signal
13 PF MOT3/A O 0/24 V DC
(pulse)
Paper feed motor 3 drive signal
14 PF MOT3/B O 0/24 V DC
(pulse)
Paper feed motor 3 drive signal
Connector Pin No. Signal I/O Voltage Description
