2FB/2FC-2.0
1-3-11
1. According to need, attach the correspond
language of operation unit label, MP label,
DP labels and main power switch label.
Figure 1-3-18
Figure 1-3-19
1. Attach the guide case to the machine right.
Figure 1-3-20
Attaching the language label (230 V specifications only).
MP label
DP labels
DP label
Main power switch label
Installing the guide case.
Guide case
Completion of the machine installation.
